Skylla-TG 24/50(1+1) 3-Phase 400V — Victron part number STG024050300.
Genuine Victron Energy Charge & convert, shipped free within the U.S. with the full Victron warranty. Every Victron item we sell is covered by our Price-Beat Guarantee: found it cheaper from an authorized U.S. dealer? We'll beat it.
A heavy-duty Victron battery charger for large battery banks on boats, buses and industrial vehicles.
Specifications
| Connections | |
| AC connection terminal type | screw-clamp 2.5 mm² (AWG 6) |
| Battery connection terminal type | M8 bolts |
| Enclosure | |
| Colour | Blue (RAL 5012) |
| Depth | 257 mm |
| Width | 250 mm |
| Protection category | IP21 |
| Weight | 13 kg |
| Height | 365 mm |
| Material | Aluminium |
| Standards | |
| Emission | EN 55014-2,EN-IEC 61000-3-3 |
| Safety | EN-IEC 60335-1,EN-IEC 60335-2-29 |
| Immunity | EN 55014-2,EN-IEC 61000-3-3 |
| Technical | |
| AC input frequency range | [45, 65] Hz |
| Temperature Sensor | Included |
| Remote Alarm | Potential free contacts 60V / 1A (1x NO and 1x NC) |
| Protections | Output short-circuit,High battery voltage,Over temperature,Battery reverse polarity |
| Programable | Settings can be changed via DIP switches and potentiometers |
| Power factor | 1 |
| Operating temperature range | [-40, 50] °C |
| AC input voltage | 3 x 400V |
| AC input voltage Bucket | 3 x 400 V |
| AC input voltage range | [320, 450] V |
| Recommended battery capacity range | [250, 500] Ah |
| Maximum humidity (non-condensing) | 95 % |
| Nominal battery voltage | 24 V |
| Can be used as power supply | True |
| Charge algorithm | IUoU, three stage charging |
| Charge Current house battery (Nominal Value) | 50 A |
| Charge Current starter battery | 4 A |
| Charge voltage Absorption | 28.5 V |
| Charge voltage float | 26.5 V |
| Forced cooling | True |
Datasheets
- Skylla-TG 24/50(1+1) 3-Phase 400V
- Skylla-TG 24/50(1+1) 3-Phase 400V (3D)
- Skylla-TG 24/80 (1+1) 24/100 (1+1) 48/50 (1)
- Skylla-TG 24/80 (1+1) 24/100 (1+1) 48/50 (1) (3D)
Part numbers: STG024050300 · GTIN 8719076026679
