The short version: Jackery has six SolarSaga panels and three are rated 100W, which is why this is confusing. Short answer: 40 Air for packing light, 100 Air for the best all-round camp panel, 100 Prime for the cheapest 100W, 100 Light if it has to bend over a curved roof, 200W for faster charging of a big station, and 500 X when you want to refill a 3kWh-plus unit in a day. Trap: the 100 Air will not recharge the Explorer 300 v2, 300, 300D or 240D.
Start with the station, not the panel
The panel that makes sense depends on what you are filling. A 288Wh Explorer 300D is full in a morning off a small panel. A 3,584Wh HomePower 3600 Plus off a single 100W panel is a multi-day proposition and not a serious plan.
Rough guide: pair panels to roughly a quarter of your capacity in watts as a comfortable daily top-up. A 1kWh station is happy with 200W of panel. A 3kWh-plus station wants 500W or more if you actually intend to live off it.
The small one: SolarSaga 40 Air
The 40 Air is 40W at 0.9 kg. Bifacial cells rated at 23% efficiency pick up reflected light off the ground, it is IP68 and IEC-certified, and a four-corner mounting system lets you hang, strap or attach it almost anywhere. Dual USB ports charge phones directly without the station.
This is the one for a rooftop tent, a motorcycle, or keeping a small unit topped up. It is not going to meaningfully charge anything over 1kWh.
The three 100W panels, and how they differ
Here is where people get stuck. All three are 100W. They are built for different situations.
- SolarSaga 100 Air — 3.2 kg, which Jackery says is 27% lighter than an average 100W panel. Bifacial PERC cells at 23%, IP68, tested through 4,000 fold cycles, with an integrated aluminium stand that sets up in about 60 seconds and takes ground stakes for windy sites. Dual USB ports as well. The best all-round camp panel of the three.
- SolarSaga 100 Prime — an unshaded front layout so the whole cell area sees sun, with a patented arc frame that doubles as the stand. It ships with a 9.58 ft cable, an Anderson to DC8020 adapter and a Z-bracket kit, which makes it the easy one to semi-permanently mount. Usually the cheapest way into 100W.
- SolarSaga 100 Light — 2.05 kg and bends up to 221 degrees, with 25% bifacial cells, IP68, IEC certification and a -40 F to 185 F range. This is the one for a curved van or RV roof, or draping over a tent. Buy it for the flexibility, not because it is better in full sun.
The compatibility trap
Worth reading twice: Jackery lists the SolarSaga 100 Air as not compatible with the Explorer 300 v2, Explorer 300, 300D or 240D for recharging. If you own one of the small units, the 100 Air is not your panel.
Separately, older Jackery stations such as the Explorer 1000, 550, 500, 300, 240 and 160 need a DC8020 to DC7909 adapter to take the 100 Prime. The SolarSaga 200W includes that adapter in the box.
SolarSaga 200W
The 200W panel uses TOPCon monocrystalline bifacial cells at about 25% conversion, is IP68 against rain, snow, sand and dirt, and folds with adjustable stands. The box includes a 3 m multi-function cable with USB ports and the DC8020 to DC7909 adapter, so it connects to both current and older stations.
For a 1kWh to 2kWh station this is the sweet spot: enough to meaningfully refill in a day without being awkward to carry or store.
SolarSaga 500 X
The 500 X is not a single panel. It is six 85W panels that fold into one pack of about 22 lb, giving 500W total. TOPCon bifacial cells at 25%, IP68, an operating range of -40 to 85 C, and an M-shaped array with ground stakes rated for winds up to level 10.
Two things to know. You can deploy just some of the six panels if the site is partly shaded, which is genuinely useful. And Jackery is explicit that it is a portable array, not intended for permanent installation, so it is not a substitute for roof-mounted panels.
This is the right partner for a HomePower 3000, 3600 Plus or Explorer 5000 Plus. The 5000 Plus in particular accepts up to 4,000W of solar input, so a single 500 X is well within its appetite.
The cable nobody budgets for
Panels want sun, stations want shade, and campsites rarely offer both in the same spot. The 10m DC Extension Cable Plus is 32.8 ft of 14 AWG copper with DC8020 connectors on both ends and UL2464 insulation. It is the cheapest upgrade to a solar setup that actually changes where you can park.
FAQ
Can I mix panel models?
Series and parallel rules and connector types vary, so check your station's solar input limits before combining. The safest approach is matching panels, which is why the 500 X ships as six identical 85W units.
Are these panels waterproof?
The current SolarSaga panels are IP68 rated. That covers rain and dust in normal use. It does not mean you should leave them deployed in a storm, given the wind loading on a folding panel.
Do the panels come with cables?
Yes. Jackery includes the cables, and the 100 Prime also ships with a Z-bracket kit and an Anderson to DC8020 adapter.
Can I leave one mounted on the roof?
The 500 X is explicitly not for permanent installation. For a fixed roof array, look at rigid panels instead; we carry those from other brands in our solar collection.
