Rich Solar 2 Pole Outdoor Circuit Breaker Box Outdoor Circuit Breaker Box with 2 Poles and Solar Isolator Disconnect Switch

Features

• Dual-Pole Circuit Protection: Provides reliable protection for AC and DC circuits with a 4,000A breaking capacity.

• Wide Voltage Compatibility: Supports AC 90–400V and DC 12–400V systems.

• IP65 Weatherproof Enclosure: Protects against water, dust, and harsh environments.

• Transparent Flip Cover: Enables quick visual status checks without opening the enclosure.

• Industrial-Grade PC/ABS Housing: Impact-resistant construction ensures long-lasting durability.

• Built-in DIN Rail Design: Simplifies installation of circuit breakers and DIN rail components.

• Enhanced Copper Bus Bars: Expanded neutral and ground terminals ensure secure electrical connections.

• Pre-drilled Wiring Ports: Simplify cable routing and installation.

• Easy Wall Mount Installation: Enables fast, secure installation on flat surfaces.

• Ideal for Solar Power Systems: Perfect for solar PV systems, RVs, and off-grid applications.

Specifications

• Number of Poles: 2P

• Current Ratings: 30A, 40A, 60A, 80A, 120A, 150A, 200A, 250A

• Rated Voltage: AC 90–400V; DC 12–400V

• Rated Frequency: 50/60Hz

• Breaking Capacity: 4,000A

• Endurance: ≥4,000 Operations (30A–60A); ≥20,000 Operations (80A–250A)

• Protection Rating: IP65 Exterior / IP20 Interior

• Operating Temperature: 23°F to 104°F (-5°C to 40°C)

• Enclosure Material: Industrial-Grade PC/ABS

• Mounting: Wall Mount with Built-in DIN Rail

• Package Dimensions: 9 × 6 × 5 in

• Gross Weight: 2 lb

Part numbers: RS-CB2P30, RS-CB2P40, RS-CB2P60, RS-CB2P80, RS-CB2P120 (UPC 650380715751, 650380715744, 650380715737, 650380715720, 650380715713)
