Features
- Advanced Circuit Protection: Protects DC systems from overloads and short circuits with a 3,000A @ 30VDC interrupt rating.
- Manual Reset Function: Features a push-to-trip button and reset lever for easy testing and quick power restoration.
- IP67 Waterproof Housing: Sealed construction protects against water, dust, and harsh outdoor environments.
- UL94 V-0 Flame-Retardant Housing: Durable thermoplastic housing with insulated terminals enhances safety and long-term reliability.
- Panel or Surface Mount: Supports flexible installation with 1/4"-28 or 3/8"-16 threaded stud terminals.
- 25A–250A Current Options: Available in multiple current ratings to support a wide range of DC power applications.
- Industry-Recognized Certifications: Meets SAE J1625, SAE J1171, ABYC E-11, and CE standards for dependable performance.
Specifications
-
Current Ratings: 25A–250A
-
Rated Voltage: 30VDC, 48VDC
-
Interrupt Rating: 3,000A @ 30VDC
-
Operating Temperature: -25°F to 180°F
-
Storage Temperature: -30°F to 300°F
-
Housing Material: UL94 V-0 Flame-Retardant Thermoset Plastic
-
Terminal Type: 1/4"-28 or 3/8"-16 Threaded Studs
-
Max Terminal Torque: 50 in-lbs (5.6 N·m)
-
Mounting: Panel or Surface Mount
-
Waterproof Rating: IP67
-
Certifications: SAE J1625, SAE J1171 (Ignition Protected), ABYC E-11, CE
-
Package Dimensions: 4 × 6 × 3 in
- Gross Weight: 1 lb
Part numbers: RS-CB40, RS-CB60, RS-CB80, RS-CB100, RS-CB120, RS-CB150, RS-CB200, RS-CB250, RS-CB30 (UPC 650380715652, 650380715645, 650380714808, 650380715638, 650380715621, 650380715614, 650380715607, 650380715591, 650380714709)
