DualPRO Eagle HF ES800 48V 17A 800W Marine On-Board Battery Charger, Ring Terminals with Inline Fuses
    DualPRO Eagle HF ES800 48V 17A 800W Marine On-Board Battery Charger, Ring Terminals with Inline Fuses
DualPRO Eagle HF ES800 48V 17A 800W Marine On-Board Battery Charger, Ring Terminals with Inline Fuses

DualPRO Eagle HF ES800 48V 17A 800W Marine On-Board Battery Charger, Ring Terminals with Inline Fuses | ES0800-48V003

$626.99
$626.99
$659.99
✓ Lowest Price Guaranteed  ·  We check U.S. dealer prices every week. Found it cheaper? We’ll beat it.
↻ 30-day price protection  ·  If our price drops after you buy, we email you the difference as store credit. Details
<p>Earn%20[points_amount]%20when%20completing%20this%20purchase.</p>
Not sure this is the right size? Answer a few quick questions and we’ll size your battery, solar and inverter — use the free calculator.
✓ Free Shipping  ·  ✓ Free 30-Day Returns
Prepaid return label, no restocking fee. Details

Shipping: Ships from Upland in 3–7 days.

The DualPRO Eagle HF ES0800-48V003 is an 800W high-frequency charger for 48V battery packs, delivering 17A with a universal 85-270 VAC input. It charges Wet Cell, AGM, Gel and Lithium batteries with selectable charge profiles, is CAN capable and PROView Link app enabled for monitoring and over-the-air updates, and can be paralleled when more output is needed. IP67 rated, 11 lb, US designed and assembled, and convertible between on-board and portable use with the optional handle kit.

Genuine DualPRO (PRO Charging Systems) product, sold new by RV Parts Giant. Ships free to the lower 48 states. Covered by the manufacturer's warranty (3 Years).

Key features

  • 800W high-frequency output: 17A at 48V
  • Universal AC input 85-270 VAC, 50/60 Hz
  • Selectable profiles for Wet Cell, AGM, Gel and Lithium
  • CAN capable; PROView Link app enabled with over-the-air updates
  • Can be paralleled for higher output
  • IP67 rated, 11 lb, 10 x 7.15 x 4 in
  • Convertible on-board / portable with optional 40576KIT handle kit
  • US designed and assembled

Specifications

  • Series: Eagle HF Series (ES0800)
  • System voltage: 48 V
  • Total output: 17 Amps
  • Output banks: 1
  • Output per bank: 17 A
  • Charge profile: PROVolt Multi Stage
  • Battery chemistry: Flooded / AGM / Gel/Li via ProView Link
  • App: ProView
  • Connectivity: Bluetooth
  • AC input: 100-240 VAC
  • Operating / storage temperature: Operating: -30°C to 70°C; Safe Storage: -40°C to 85°C
  • Maintenance charging: Yes
  • Mounting: On-board
  • IP rating: IP67
  • AC cable length: 12in w/ 3ft adaptor
  • DC cable length: 5 ft
  • Connector / terminals: IEC (AC) / Ring Terminals (DC), inline fuses
  • Certifications: FCC 15 Parts A & B compliant, ignition protected
  • Country of origin: USA
  • Warranty: 3 Years
  • Dimensions (L x W x H): 10 x 7.15 x 4 in
  • Weight: 11 lb
  • Shipping weight: 12.1 lb

What's included

  • Charger
  • Manual

Part number: ES0800-48V003; UPC 738562003572

Shop the full DualPRO range at RV Parts Giant.

Is the ES0800-48V003 the right ES800?

  • Battery system: 48V, connected with ring terminals with inline blade fuses and an IEC AC inlet.
  • Made for: boats: a single 48V battery, or batteries in series with DualPRO's B.O.S. (sold separately by DualPRO; check with DualPRO which B.O.S. suits a 48V string).
  • Battery types: flooded, AGM, gel or lithium, selected in the free PROView Link app. Check your battery maker's charge settings first.

More: which Eagle HF ES800 version; all DualPRO.
