The Victron Quattro is an inverter/charger with two AC inputs. Shore power and a generator can both stay wired in, and the Quattro connects to whichever one is live. That makes it the usual choice for Class A motorhomes, large fifth wheels and toy haulers that carry an onboard generator. This guide covers the 120V Quattro models sold in North America, how to read the model code, what PowerControl and PowerAssist do, how the Quattro-II 2x120V differs, and how to size one. For the quick comparison with the single-input units, see our MultiPlus vs MultiPlus-II vs Quattro overview.
What the Victron Quattro does
The Quattro combines four jobs in one box: a pure sine wave inverter, a multi-stage battery charger, an automatic transfer switch and a two-input source selector. According to Victron's datasheet, it can be connected to "two independent AC sources", for example shore power and a generator, or two generators, and it automatically connects to the active one. You don't need a separate generator transfer switch.
- Main AC output, no-break: if shore or generator power drops, the Quattro takes over the connected loads in less than 20 milliseconds, fast enough that computers and other electronics keep running.
- Second AC output, input-only: this output is live only while AC is present on one of the inputs. Put loads that should never drain the battery on it, such as an electric water heater element.
- Programmable relays: the 120V Quattro has three. One can be set for generator start/stop, and a GX device such as the Cerbo GX or Ekrano GX adds full generator auto-start.
PowerControl and PowerAssist
PowerControl: you set a current limit on each AC input. The Quattro accounts for the other AC loads and uses only the spare current for charging, so it never overloads a small generator or a 30A pedestal.
PowerAssist goes a step further. When the loads need more than the shore or generator supply can give, the Quattro adds battery power on top of the incoming AC instead of letting the breaker trip. When the load drops, it uses the spare power to recharge the battery. On a coach running an air conditioner, microwave and water heater from a limited supply, this is the feature that keeps the pedestal breaker from tripping.
How to read a Quattro model code
Take Quattro 48/5000/70-100/100 120V:
- 48: battery bank voltage (12, 24 or 48V). This must match your bank.
- 5000: continuous inverter output in VA at 25°C (77°F).
- 70: charger current in amps.
- 100/100: maximum current each of the two AC inputs can pass through.
- 120V: the North American output version. Variants marked UL 1741 (48V 5 kVA and 10 kVA) or UL 458 (12V and 24V 5 kVA) carry those UL certifications.
- One quirk: the 12V model is named 12/5000/220, but Victron's datasheet rates its house-battery charger at 200 A, which is the figure in the table below.
Victron Quattro 120V models compared
Figures from Victron's Quattro 120V datasheet (3 kVA to 10 kVA):
| Model (120V) | Battery | Continuous output at 25°C | Peak | Charger | AC inputs | Weight |
|---|---|---|---|---|---|---|
| 48/3000/35-50/50 | 48V | 3,000 VA / 2,400 W | 6,000 W | 35 A | 2 x 50 A | 42 lb |
| 12/5000/220-100/100 | 12V | 5,000 VA / 4,000 W | 10,000 W | 200 A | 2 x 100 A | 75 lb |
| 24/5000/120-100/100 | 24V | 5,000 VA / 4,000 W | 10,000 W | 120 A | 2 x 100 A | 66 lb |
| 48/5000/70-100/100 | 48V | 5,000 VA / 4,000 W | 10,000 W | 70 A | 2 x 100 A | 66 lb |
| 48/10000/140-100/100 | 48V | 10,000 VA / 8,000 W | 20,000 W | 140 A | 2 x 100 A | 128 lb |
Continuous output falls as temperature rises. The 5 kVA models are rated 4,000 W at 25°C, 3,700 W at 40°C (104°F) and 3,000 W at 65°C (150°F), so a hot, unventilated bay costs you real capacity. The 12V and 24V models also have a 4 A starter-battery charge output. All 120V Quattros accept 90–140 VAC on their inputs and are IP21, meaning they must be mounted in a dry compartment. A 277V 15 kVA Quattro also exists, but it is a commercial model, not an RV unit.
Quattro vs Quattro-II 2x120V
The classic 120V Quattro outputs single-phase 120V. The Quattro-II 2x120V is built for North American 50A service. It accepts and passes through both legs of a 120/240V split-phase shore or generator supply, so the full 50A service passes through to your AC loads. Charging power is drawn from L1, and PowerControl and PowerAssist act on the L1 input. On a single-phase 120V supply it takes power on L1 and feeds 120V to both output lines. When it is inverting from the battery, its output is 120V single-phase. 240V is available only while a split-phase source is connected, which stops heavy 240V loads from draining the battery.
The two Quattro-II 2x120V models are 12/3000/120-50/50 and 24/3000/70-50/50: 3,000 VA, two 50 A inputs, 120 A or 70 A of charging, and one programmable relay (the classic Quattro has three). Choose the Quattro-II 2x120V when your coach has a 50A split-phase panel and about 3 kVA of inverting is enough. Choose a 5 kVA or 10 kVA Quattro when you need more inverter power. Several 120V units can be set up together for split-phase (see below).
Parallel, split-phase and three-phase systems
Victron's 120V datasheet says two Quattros can be configured for split-phase output and three for three-phase. For more power, up to four sets of three units can be connected in parallel. Victron's product page puts the parallel limit at up to six Quattros, and the exact per-phase maximum varies by model (Victron's parallel manual lists it). Paralleled units must be the same model and firmware, and the system is set up with Victron's VE.Bus configuration software, so it is worth getting the design checked before you buy.
Sizing a Quattro for your RV
- Start from the loads you must run on battery, not from the shore rating. Add up the running watts of everything on the inverter (no-break) output at the same time, and keep it under the continuous watt rating at the temperature of your install bay.
- Match the battery voltage to your inverter size. A 5 kVA unit on 12V draws very high DC current, so the cables and fusing get heavy. Above 5 kVA, Victron's 120V Quattro is offered only in 48V, and a 48V bank keeps cable sizes manageable.
- Size the battery bank to the charger and inverter. Lithium banks need a BMS that the Quattro can be told about. See our Victron lithium batteries, and our Lynx DC distribution range for busbars and fusing.
- Put the water heater and 240V loads on the right output. Loads that should only run on shore or generator power belong on the second output.
Quattro or two stacked MultiPlus-II units?
A pair of 120V MultiPlus-II units can also be configured for split-phase. Each MultiPlus-II has only one AC input, though, so switching between shore power and a generator still needs an external transfer switch. The Quattro builds that in, which means fewer boxes and less wiring in a vehicle that vibrates down the highway. If your rig has no generator, a MultiPlus-II is usually the simpler and lighter choice.
The rest of a Quattro system
A typical install adds:
- a GX device for monitoring, VRM remote access and generator auto-start
- a SmartShunt or BMV battery monitor
- Lynx distribution with correct fusing
- SmartSolar MPPT charge controllers, so the generator becomes the backup rather than the plan
Victron lists a 5-year standard warranty on the Quattro.
Victron Quattro FAQ
Does the Victron Quattro need an external transfer switch?
No. It has an integrated transfer switch and two AC inputs, and it connects automatically to whichever source is live.
Can a Victron Quattro run on a 30A pedestal?
Yes. Set the input current limit to 30A. PowerControl then charges only from the spare current, and PowerAssist adds battery power when loads exceed the pedestal.
Which Quattro gives 240V in an RV?
The Quattro-II 2x120V passes through 120/240V split-phase when it is supplied by a split-phase source. Two 120V Quattros can also be configured for split-phase output.
Is the Victron Quattro compatible with lithium batteries?
Yes. Victron describes the 120V Quattro as lithium-ion battery compatible. Set the charge profile to your battery maker's figures, and integrate the battery's BMS through a GX device.
How fast does the Quattro switch to battery?
Victron rates the no-break switchover at less than 20 milliseconds.
